2.4GHz 150Mbps Outdoor CPE
You Might Also Want to Add
More infoMake 4 interest-free payments of $27.27 fortnightly and receive your order now.
Features:
O3 2.4GHz Outdoor CPE is designed to WISP CPE solutions and long distance wireless network solutions for video surveillance and data transmission. It features with 12dBi directional antenna to provide an efficient way to pick up and maintain a stable signal for a wireless network. Adopt of auto-bridging technology,two CPE can connect to each other automatically to make it easy to setup.
| Mode | O3 |
| Dimension | 270 × 94.86 × 67.5mm |
| Deployment | Pole Mount |
| Application Scenarios | WISP CPE, Data transmission and Long range video surveillance |
| Frequency | 2.4GHz |
| Maximum wireless speed | 150Mbps |
| Interface | 2 × 10/100Mbps Ethernet Port |
| Antenna | 12dbi |
| Antenna Beamwidth | Horizontal: 60° Elevation: 30° |
| Reset Button | 1 |
| GND Terminal | 1 |
| Power Consumption | 4.3W |
| Waterproof Level | IP64 |
| LED indicator | PoE/LAN,LED1,LED2,LED3 |
| Power Method | 12V1A Passive PoE |
| Passive PoE power supply | Passive power over ethenet via PoE/LAN ( 4,5pins -7,8pins) Voltage range: 11-13.8V DC |
| Reception Sensitivity | MCS0: -96dbm MCS7: -72dbm |
| Operating mode | AP/Station/WISP/P2MP/WDS Repeater/Router |
| Standard & Protocol | IEEE 802.11b/g/n |
| Enable/Disable Wireless Radio | Support |
| SSID Hidden | Support |
| Wireless Client isolation | Support |
| SSID Isolation | Support |
| Client Limitation For SSID | Support |
| Wireless Access Control | Support |
| Weak Signal Client Limitation | Support |
| Transmit Power | Adjustable power by 1dBm |
| WMM Capable | Support |
| APSD Capable | Support |
| Wireless Security | 64/128 WEP,WPA-PSK,WPA2-PSK,WPA & WPA2-PSK,WPA,WPA2 |
| Transmission Media | Support |
| VLAN Tagging for SSID | Support |
| DHCP Server | Support |
| VPN Pass-through | PPTP,L2TP |
| Remote Web access | Support |
| Schedule Reboot | Support |
| Page Timeout | Support |
| Ping Watchdog | Support |
| Dyndns | noip, dyndns.org |
| Network Diagnoses | Ping, Traceroute, Signal Scan |
| Time & Date Setting | Support |
| Firmware Upgrade | Support |
| Backup/Restore Configuration | Support |
| Username Managerment | Support |
| Syslog | Support |
| Managed By Controller | PC Software -- CPE Assistant |
| Temperature | Operating Temperature: -30°C ~ 60°C Storage Temperature: -40°C ~ 70°C |
| Humidity | Operating Humidity: 10%~90% non-condensing Storage Humidity: 10%~90% non-condensing |
| Default Settings | Default login IP: 192.168.2.1 Default Login Username: admin Default Login Password: admin |
| Certification | FCC/CE/RoHS |
Package Content
1 × 5km Point to Point Outdoor CPE
1 × Power Adapter
1 × PoE Injector
2 × Plastic Staps
1 × Quick Installation Guide
